FIRE-RATED ROLLER SHUTTER DOOR
The Fire-Rated Roller Shutter Doors is ideal for openings requiring a counter-type fire-rated door. Common applications include factories, schools, concessions, hospitals, cafeterias and retail settings. Labeled with either a 3-hour Class A rating for masonry applications, or 2-hour Class B label in non-masonry fire walls, these doors are designed to expand upward in a fire, allowing the guides to be installed flush with the sill. This fire roller shutter doors can be custom designed for conveyor openings. This fire-rated counter door has exposed components made of primed galvanized steel. A host of standard and optional features further enhance performance of these doors for fire-rated applications.
TEL: 0086-13524123918
Email: sale@industry-doors.com
- Flame baffle system.
- Vision lites.
- Smoke detectors.
- Crank or electric operation.
- Electric operation does not require tension reset after drop test or closure due to power loss.
- Powder powder coat finish options are available in any RAL color.
Standard max width
7000mm
Standard max height
3500mm
Fire-Rated time
3 hour or 2 hour
Curtain
Flat slat curtain design in primed galvanized steel with baked-on polyester powder coat finish in white, brown, gray or any RAl colors.
Fusible link for added safety
Separates at 165°F (74°C) to automatically close the door in case of fire
Controlled rate of descent
Governor controls rate of door descent during a fire
Attractive appearance
Compact box guide design for an attractive appearance
Automation
with side-mounted certificated fire-rated roller door motor
Warranty
3 years
